Benjamin Tubefittings is a well-respected manufacturer and supplier located in Abuja, Nigeria, specializing in top-notch **Carbon Steel EN-31 Bars**. With a reputation for precision engineering and a commitment to international standards, the company guarantees that its products deliver exceptional strength, durability, and reliability. These bars are crafted to meet stringent mechanical and chemical specifications, making them perfect for critical industrial applications. Benjamin Tubefittings caters to various sectors, including automotive, machinery, construction, and engineering, providing carbon steel bars that ensure long-lasting performance, structural integrity, and consistent quality across a broad spectrum of engineering and manufacturing processes.
Carbon Steel EN-31 Bars are primarily made up of carbon, manganese, phosphorus, sulfur, and silicon, featuring a high carbon content of about 1.0–1.1%. This composition gives them remarkable hardness, wear resistance, and tensile strength. Manganese boosts toughness and impact resistance, while phosphorus and sulfur are carefully regulated to enhance machinability. Typically, these bars showcase tensile strength between 850–1000 MPa and yield strength around 620 MPa. Their outstanding mechanical properties make them perfect for heavy-duty applications, providing high resistance to fatigue, wear, and deformation even under tough conditions.
| Grade | En31 |
|---|---|
| Specification | 100Cr6, AISI SAE E52100, 100Cr6, 2258, 100C6 |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Square bar size | 4 to 100mm |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Section | 3.0 to 12.0mm thickness |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2″ to 495mm Diameter |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Finish | Cold (bright) drawn, centreless ground,smooth turned, peeled, slit rolled edge, hot rolled, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Condition | Hardened & tempered, annealed |
| Technique | en31 Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Processing | Bar cutting to 650mm |
| Form | en31 Welding Rod, Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Our stockyad location for fast delivery across India | Surendranagar, Rajkot, Ranjangaon, Indore, Ahmedabad, Bhosari, Surat, Baroda, Chennai, Chakan, Hyderabad, Ahmednagar, Ajmer, Kolhapur, Thane, Belgaum, Kadi, Aurangabad, Pune, Hubli Mumbai, Nagpur, Jaipur, Nashik, Navi Mumbai |
| Carbon | 0.95 / 1.10 |
| Manganese | 0.40 / 0.70 |
| Silicon | 0.10 / 0.35 |
| Sulfur | Max 0.050 |
| Phosphorus | Max 0.040 |
| Chromium | 1.20 – 1.60 |
| Thermal Conductivity at °C | 20 | 350 | 700 |
| W/(m*K) | 44.5 | 45.0 | 46.0 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Cut to size on request (tolerance +2/-0 mm). Standard lengths of en31 Bars 2000 mm up to 6000 mm available | |||
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
These Carbon Steel EN-31 Bars find extensive use in producing gears, shafts, rollers, studs, and high-strength machine components. They are ideal for applications that demand high hardness, wear resistance, and durability, including automotive, tool-making, and industrial machinery. Additionally, these bars are well-suited for heat treatment processes like hardening and tempering to achieve the desired mechanical properties. Their impressive strength, toughness, and reliability make them a go-to choice in industries where precision, durability, and performance are essential for long-term operational efficiency.
Samuel Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Abuja, Nigeria.
