Welcome to Samuel Steels, your trusted partner for industrial-grade fastening solutions right here in Abuja. We specialize in supplying high-strength Alloy Steel Grade 8.8 Bolts, engineered to meet the rigorous demands of Nigeria’s dynamic construction and manufacturing sectors. Our commitment is to provide not just products, but reliability, ensuring every bolt delivers the exceptional performance and durability your critical projects require. When you choose Samuel Steels, you’re choosing a foundation of strength and local expertise you can count on.
The composition of these bolts is a careful balance, primarily carbon steel enhanced with elements like boron to achieve their notable strength. This results in a minimum tensile strength of 800 MPa and a yield strength of 640 MPa, which is the real measure of their load-bearing capacity before they permanently deform. This excellent strength is paired with good toughness, making them resistant to shock and fatigue, which is essential for components that need to hold firm under stress and vibration over time.
| AStm Standards | DIN ISO EN 4017 & 4014 DIN 933 / 931 & IS 1363 / 1363 |
| Size | Diameter 20 to 100 Milimeter / Inch 3/4 to 3.1/2 |
| Surface Finish | Zinc plated / Plain / Hot dip galvanised |
| CLASS | MATERIAL AND TREATMENT | C | C | P | S | B | TEMPERING TEMP. [C] |
|---|---|---|---|---|---|---|---|
| MIN | MAX | MAX | MAX | MAX | |||
| 8.8 | CARBON STEEL WITH ADDITIVES (E.G. B, MN OR CR) QUENCHED AND TEMPERED | 0.15 (D) | 0.4 | 0.025 | 0.025 | 0.003 | 425 |
| CARBON STEEL QUENCHED AND TEMPERED | 0.25 | 0.55 | 0.035 | 0.025 |
| Grades | Size Range | PS [MPa] | YS (min) [MPa] | TS (min) [MPa] | Hardness [Rockwell] |
|---|---|---|---|---|---|
| Class 8.8 | Under M16 | 580 | 640 | 800 | |
| 17-72 | 600 | 660 | 830 | C23–34 |
| Bolt Dia | Body Dia | Head Dia(F) | Head Height (H) | Degree of Slope | |||
|---|---|---|---|---|---|---|---|
| (D) | Max | Max Edge Sharp | Min Edge Sharp | Absolute Min Rounded | Max | Min | Â |
| 1/2 | 0.515 | 0.935 | 0.905 | 0.845 | 0.269 | 0.233 | 78° to 82° |
| 5/8 | 0.642 | 1.169 | 1.132 | 1.066 | 0.336 | 0.292 | 78° to 82° |
| 3/4 | 0.768 | 1.402 | 1.357 | 1.285 | 0.403 | 0.349 | 78° to 82° |
| 7/8 | 0.895 | 1.637 | 1.584 | 1.511 | 0.47 | 0.408 | 78° to 82° |
| 1 | 1.022 | 1.869 | 1.81 | 1.735 | 0.537 | 0.466 | 78° to 82° |
| 1-1/8 | 1.149 | 2.104 | 2.037 | 1.962 | 0.604 | 0.525 | 78° to 82° |
| 1-1/4 | 1.277 | 2.337 | 2.262 | 2.187 | 0.671 | 0.582 | 78° to 82° |
| 1-3/8 | 1.404 | 2.571 | 2.489 | 2.414 | 0.738 | 0.641 | 78° to 82° |
| 1-1/2 | 1.531 | 2.804 | 2.715 | 2.64 | 0.805 | 0.698 | 78° to 82° |
| Dimensions per ASME B18.5 1990 (R 1998) | |||||||
| Diameter Chart | M4 | M5 | M6 | M8 | M10 | M12 | M14 | M16 | M18 | M20 | M22 | M24 | M27 | M30 | M33 | M36 | M39 | M42 | M45 | M48 | M52 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Pitch List | 0.7 | 0.8 | 1 | 1.25 | 1.5 | 1.75 | 2 | 2.5 | 3 | 3.5 | 4 | 4.5 | 5 | ||||||||
| GR A Length | 40 | 50 | 60 | 80 | 100 | 120 | 140 | 150 | Grade A not applicable to these dia’s | ||||||||||||
Head Across Flat (S) Nom = Max Min GR A GR B | 7 | 8 | 10 | 13 | 16 | 18 | 21 | 24 | 27 | 30 | 34 | 36 | 41 | 46 | 50 | 55 | 60 | 65 | 70 | 75 | 80 |
| 6.78 | 7.78 | 9.78 | 12.73 | 15.73 | 17.73 | 20.67 | 23.67 | 26.67 | 29.67 | 33.38 | 35.38 | GR A not applicable to these diameters | |||||||||
| 6.64 | 7.64 | 9.64 | 12.57 | 15.57 | 17.57 | 20.16 | 23.16 | 26.16 | 29.16 | 33 | 35 | 40 | 45 | 49 | 53.8 | 58.8 | 63.1 | 68.1 | 73.1 | 78.1 | |
Head Height Nom Tol + or – GR A GR B | 2.8 | 3.5 | 4 | 5.3 | 6.4 | 7.5 | 8.8 | 10 | 11.5 | 12.5 | 14 | 15 | 17 | 18.7 | 21 | 22.5 | 25 | 26 | 28 | 30 | 33 |
| 0.125 | 0.15 | 0.18 | 0.215 | GR A not applicable to these diameters | |||||||||||||||||
| 0.2 | 0.24 | 0.29 | 0.35 | 0.42 | 0.5 | ||||||||||||||||
Across corners e Min GR A GR B | 7.66 | 8.79 | 11.05 | 14.38 | 17.77 | 20.03 | 23.36 | 26.75 | 30.14 | 33.53 | 37.72 | 39.98 | GR A not applicable to these diameters | ||||||||
| 7.5 | 8.63 | 10.89 | 14.2 | 17.59 | 19.85 | 22.78 | 26.17 | 29.56 | 32.95 | 37.29 | 39.55 | 45.2 | 50.85 | 55.37 | 60.79 | 66.44 | 71.3 | 76.95 | 82.6 | 88.25 | |
Thread Length (b) For lengths < or = 125ilimeter For lengths > 12ilimeter <= 200milimeter For lengths > 200ilimeter | 14 | 16 | 18 | 22 | 26 | 30 | 34 | 38 | 42 | 46 | 50 | 54 | 60 | 66 | Not specified as full thread recommended | ||||||
| 20 | 22 | 24 | 28 | 32 | 36 | 40 | 44 | 48 | 52 | 56 | 60 | 66 | 72 | 78 | 84 | 90 | 96 | 102 | 108 | 116 | |
| 33 | 35 | 37 | 41 | 45 | 49 | 53 | 57 | 61 | 65 | 69 | 73 | 79 | 85 | 91 | 97 | 103 | 109 | 115 | 121 | 129 | |
| Major Diameter at thread (minimum) | 3.838 | 4.826 | 5.794 | 7.76 | 9.732 | 11.701 | 13.682 | 15.682 | 17.623 | 19.623 | 21.623 | 23.577 | 26.577 | 29.522 | 32.522 | 35.465 | 38.465 | 41.437 | 44.437 | 47.399 | 51.399 |
| Major Dia at thread (maximum) | 3.978 | 4.976 | 5.974 | 7.972 | 9.968 | 11.966 | 13.962 | 15.962 | 17.958 | ||||||||||||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Alloy Steel Gr 8.8 Bolts in Abuja, Nigeria. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your Alloy Steel Gr 8.8 Bolts needs!
You’ll find these Grade 8.8 bolts at work in countless essential applications, forming the sturdy backbone of modern infrastructure. They are the preferred choice for structural steel connections in building frames, bridges, and industrial plants, where their reliability is non-negotiable. Beyond construction, they are vital in assembling heavy machinery, automotive parts, and various industrial equipment. Essentially, wherever there’s a need for a strong, dependable fastening solution that can handle significant loads, these bolts provide the secure connection that keeps everything safely together.
Samuel Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Abuja, Nigeria.
