In the heart of Nigeria’s dynamic capital, Samuel Steels stands as a trusted partner for industry, providing essential components that build the very framework of Abuja’s growth. We specialize in the supply of high-integrity Alloy Steel Gr B7M Fasteners, offering a reliable source for the robust bolts and studs that are critical for projects demanding unwavering strength and exceptional corrosion resistance, ensuring the safety and longevity of vital infrastructure and industrial applications.
Alloy Steel Gr B7M fasteners are defined by a specific chemical composition, primarily chromium and molybdenum, which is carefully balanced to achieve their distinctive properties. The real differentiator, however, is their mechanical strength, which is developed through a precise heat-treatment process. This controlled treatment not only provides high tensile strength but also ensures a maximum hardness that is intentionally limited. This crucial limitation is key to providing outstanding resistance to stress corrosion cracking, a common failure point in challenging environments.
Specification :Â ASTM A 193 ASME SA 193
Standard :Â DIN, ASTM, BS and all International Standards
Length :Â 3 mm to B7M mm
Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes
Types :Â Nuts, Bolts, Screws, Sockets, Studs, Screw, Hex Set Screw, Socket Screw, Cap Screw, Pan Head Screw, Socket Head Cap Screw, Washers, Spring Washers, Studs, Anchors
| Alloy Steel B7M | C | Mn | P | S | Si | Cr | Mo |
| 0.37-0.49 | 0.65-1.10 | 0.035 Max | 0.04 Max | 0.15-0.35 | 0.75-1.20 | 0.15-0.25 |
| Grade | Size | Tensile ksi, min | Yield, ksi, min | Elong, %, min | RA % min |
|---|---|---|---|---|---|
| B7M | Up to 2-1/2 | 125 | 105 | 16 | 50 |
| 2-5/8 – 4 | 115 | 95 | 16 | 50 | |
| 4-1/8 – 7 | 100 | 75 | 18 | 50 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
|
Hexagon Bolts / Set Screws |
Stud Bolts |
Hexagon Nuts |
Socket Capscrews |
|---|---|---|---|
|
DIN 931 |
BS4882 |
DIN 934 |
DIN 912 |
|
DIN 933 |
DIN 976 |
BS 1768 |
DIN 6912 |
|
BS 1768 |
BS 1769 |
DIN 7984 |
|
|
UNI 5731 |
BS 1083 |
ANSI B18.3 |
|
|
UNI 5739 |
BS 3692 |
ISO 4762 |
|
|
ISO 4014 |
ISO 4032 |
UNI 5931 |
|
|
ISO 4017 |
ISO 4033 |
BS 2470 |
|
|
BS 1769 |
ANSI B18.2.2 |
BS 4168 |
|
|
BS 3692 |
|||
|
ANSI B18.2.1 |
|||
|
Socket & Slotted Set Screws |
Socket & Slotted Countersunk Screws |
Studs |
Washers |
|
DIN 913 |
DIN 963 |
DIN 938 |
DIN 125 |
|
DIN 914 |
DIN 7991 |
DIN 939 |
DIN 9021 |
|
DIN 915 |
BS 4168 |
DIN 2510 |
BS 4320 |
|
DIN 916 |
BS 1981 |
BS 4439 |
BS 3410 |
|
DIN 551 |
BS 483 |
BS 2693 |
|
|
DIN 553 |
BS 2470 |
Spring Washers |
|
|
DIN 438 |
DIN 127 |
||
|
BS 4168 |
BS 4464 |
||
|
BS 1802 |
The primary use for these specialized fasteners is in situations where standard high-strength bolts would be at risk. They are indispensable in the oil and gas industry for pressure vessels, wellheads, and piping systems that handle sour gas containing hydrogen sulfide. Beyond energy, they are vital in chemical processing plants, power generation facilities, and refinery equipment—any application where components are under significant tension while simultaneously exposed to corrosive agents that can lead to sudden, brittle failure.
