Samuel Steels has established itself as a trusted name for industrial materials in Abuja, Nigeria, providing reliable solutions to a diverse range of businesses. We take pride in being your local source for high-performance alloys, including the versatile Alloy Steel Grade 11 Foil. Our commitment goes beyond supply; we focus on building partnerships by ensuring consistent quality and providing the technical support our clients need to succeed, making sophisticated materials accessible right here in the heart of the nation’s capital.
The strength of Alloy Steel Grade 11 Foil comes from its thoughtful composition, which features a molybdenum-chromium blend that gives it a distinct edge. This combination allows the foil to maintain excellent mechanical properties, particularly its impressive tensile strength and notable resistance to creep, even when faced with elevated temperatures. It’s this reliable performance under pressure that makes it a preferred choice for demanding environments where thinner, lighter materials are essential without sacrificing durability or integrity.
| Specifications | : | ASTM A387 / ASME SA387 |
| Thickness | : | 1mm-300mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, 4050mm etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, 12000mm, 15000mm etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| Alloy Steel Gr 11 | 0.05 – 0.17 | 0.40-0.65 | 0.50 – 0.80 | 0.035 max | 0.035 max | 1.0 – 1.5 | 0.45 – 0.65 | – | – |
| Tensile (MPa) | Yield (MPa) | Elongation (50mm) | Elongation (200mm) | Reduction of Area |
| 415 – 585 | 240 min | 22% min | 19% min | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
You’ll find Alloy Steel Grade 11 Foil playing a critical role in numerous advanced applications, especially where heat is a constant factor. It’s perfectly suited for crafting intricate gaskets and specialized seals within chemical processing equipment and power generation systems. Its formability also makes it ideal for lightweight heat exchanger components and protective linings in aerospace and automotive sectors. Essentially, this foil is the hidden hero in many technologies, quietly ensuring everything operates safely and efficiently under challenging thermal conditions.
Samuel Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Abuja, Nigeria.
