Samuel Steels is a reputable manufacturer and supplier based in Abuja, Nigeria, known for providing top-notch ASTM A242 Type 2 Corten Steel Sheets and Plates. These products are celebrated for their exceptional corrosion resistance and weathering capabilities. Designed to develop a stable, rust-like finish when exposed to the elements, they eliminate the need for painting. Adhering to international standards, Samuel Steels guarantees a superb surface finish, consistent thickness, and mechanical strength, making them perfect for both structural and architectural uses. The ASTM A242 Type 2 Corten Steel Plates are built for long-lasting durability, making them ideal for outdoor structures, bridges, facades, and industrial frameworks that face tough conditions.
ASTM A242 Type 2 Corten Steel Sheets and Plates are made up of carbon (maximum 0.12%), manganese (0.20–0.50%), silicon (0.25–0.75%), chromium (0.40–0.65%), copper (0.25–0.55%), nickel (maximum 0.30%), along with trace amounts of phosphorus and sulfur. This well-balanced composition boosts both atmospheric corrosion resistance and strength. The plates showcase a tensile strength ranging from 480 to 620 MPa, a yield strength of 340 MPa, and an elongation of 20%. When exposed to the atmosphere, the alloy forms a protective oxide layer, offering remarkable resistance to moisture, oxidation, and environmental wear over time.
Grade : ASTM A242 Type 2 Corten Steel Plates
Standard : ASTM A242 / ASME SA242
Width : 1500mm to 4050mm,
Length : 3000mm to 15000mm
Thickness : 6MM to 200
Type: Weathering Steel / Weather Resistant / Corten Steel / High-Strength Low-alloy Structural Steel
Process: Hot-Rolled (HR)
| Grade ASTM A242 TYPE 2 | C | Mn | P | S | Cu |
| 0.20 Max | 1.35 Max | 0.04 | 0.05 | 0.20 Min |
| Properties | Conditions | ||
| T (°C) | Treatment | ||
| Density (×1000 kg/m3) | 7.7-8.03 | 25 | |
| Poisson’s Ratio | 0.27-0.30 | 25 | |
| Elastic Modulus (GPa) | 190-210 | 25 | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
ASTM A242 Type 2 Corten Steel Sheets and Plates find extensive use in architectural, structural, and industrial projects that demand long-lasting durability with minimal upkeep. They’re perfect for building facades, bridges, outdoor sculptures, chimneys, and railway wagons, thanks to their self-protecting surface layer. In industrial settings, they’re utilized in containers, storage tanks, and transport equipment. The unique weathered appearance also makes them a favorite in contemporary architectural and landscaping designs. With their blend of strength, corrosion resistance, and visual appeal, Corten Steel Plates are a top choice for many projects.
