Samuel Steels, located in Abuja, Nigeria, is a well-known manufacturer and exporter of premium quality Carbon Steel API X56 5L PSL 2 Pipes which are specifically tailored to work efficiently in atmospheres that are inherently aggressive. The company is geared towards offering piping products that are of the highest integrity and are capable of withstanding long usage periods whilst adhering to internationally recognized API and ISO standards. In an effort to enhance the performance of its products, Samuel Steels operates top-notch factory equipment and carries out stringent quality testing in order to attain perfection in all the product attributes such as size, strength, and rust-proofing. Their Carbon Steel API X56 5L PSL 2 Pipes find extensive applications in the oil and gas, petrochemical, and power generation sectors as a means of safe and efficient fluid transportation.
Carbon Steel API X56 5L PSL 2 Pipes are conventionally made by the combination of iron and carbon wherein the mixture comprises of small amounts of manganese, phosphorus, sulfur, and silicon for the purpose of improving the mechanical properties of the material. These pipes can achieve a very high yield strength of 386 MPa and also a tensile strength ranging from 490 to 655 MPa. They provide good weldability, toughness, and resistance to corrosion and stress as well. The right mix and excellent mechanical strength of these materials make them suitable candidates for very high-pressure and high-temperature applications thus they guarantee users long-term and failure-free performances in the most demanding industrial sectors.
| Grade of material | X56 / L390 (N, M, Q, R) |
| Standard | ISO 3183 L390/ API 5L X56 |
| API 5L X56 Seamless Pipe (OD) | 21.3 – 660mm ( Inch 1/2” – 26”) |
| X56 SAW | 16″ – 100″ NB |
| API 5L X56 PSL2 ERW and HFW | 1/2” NB – 24” NB |
| X56 Steel LSAW / DSAW | 16’OD TO 54″ OD (8 MM TO 50 MM THK) |
| API 5L X56 PSL2 Pipe end | Square Cut, Buttweld, Pub Joints, Squared Ends, Thread Cutting, Socket, Cut Grooves, Coupling, Deburring, Vibrator Grinding, Plain end (PE), Chamfering, Threaded Ends (Male & Female), Screwed, Beveled End (BE), Flanged Ends, Grooved |
| X56 Carbon Steel Pipe Length | DRL, SRL, 20FT, 40FT, Single Random Length (SRL), Double Random Length (DRL), and Fixed Length 5.8 Meter, 12.0 Meters (40FT), 6.0 Meters (20FT), 11.8 Meters, |
| API 5L X56 Wall Thickness | SCH80, SCH160, SCH-XS, SCH-XXS, SCH-STD, SCH40, |
| PSL Level | |
| Coating for API 5L X56 Line Pipe | Black Painting, CRA clad, 3PE, 3PP, 3LPE, FBE, Galvanized, lined pipe, Anti-Rust Oil, Varnished, |
| Mass fraction, based upon heat and product analysis % maximum | CARBON EQUIVALENT a | ||||||||||
| % MAXIMUM | |||||||||||
| Cb | Si | Mnb | P | S | V | Nb | Ti | Other | CEIIW | CEPcm | |
| L320N or X56 | 0.24 | 0.4 | 1.4 | 0.025 | 0.015 | 0.10f | 0.05 | 0.04 | e | 0.43 | 0.25 |
| .S | T.S | ELONGATION |
| Mpa(psi) | Mpa(psi) | |
| min | min | min |
| 390(56 600) | 545(79 000) | F |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| NPS (in) | Outside Diameter (in) | API 5L X56 Pipe Schedule | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SCH 10 | SCH 20 | SCH 30 | SCH STD | SCH 40 | SCH 60 | SCH XS | SCH 80 | SCH 100 | SCH 120 | SCH 140 | SCH 160 | SCH XXS | ||
| Wall Thickness (in) | ||||||||||||||
| 1/8 | 0.405 | 0.068 | 0.068 | 0.095 | 0.095 | |||||||||
| 1/4 | 0.540 | 0.088 | 0.088 | 0.119 | 0.119 | |||||||||
| 3/8 | 0.675 | 0.091 | 0.091 | 0.126 | 0.126 | |||||||||
| 1/2 | 0.840 | 0.109 | 0.109 | 0.147 | 0.147 | 0.187 | 0.294 | |||||||
| 3/4 | 1.050 | 0.113 | 0.113 | 0.154 | 0.154 | 0.219 | 0.308 | |||||||
| 1 | 1.315 | 0.133 | 0.133 | 0.179 | 0.179 | 0.250 | 0.358 | |||||||
| 1 1/4 | 1.660 | 0.140 | 0.140 | 0.191 | 0.191 | 0.250 | 0.382 | |||||||
| 1 1/2 | 1.900 | 0.145 | 0.145 | 0.200 | 0.200 | 0.281 | 0.400 | |||||||
| 2 | 2.375 | 0.154 | 0.154 | 0.218 | 0.218 | 0.344 | 0.436 | |||||||
| 2 1/2 | 2.875 | 0.203 | 0.203 | 0.276 | 0.276 | 0.375 | 0.552 | |||||||
| 3 | 3.500 | 0.216 | 0.216 | 0.300 | 0.300 | 0.438 | 0.600 | |||||||
| 3 1/2 | 4.000 | 0.226 | 0.226 | 0.318 | 0.318 | |||||||||
| 4 | 4.500 | 0.237 | 0.237 | 0.337 | 0.337 | 0.438 | 0.531 | 0.674 | ||||||
| 5 | 5.563 | 0.258 | 0.258 | 0.375 | 0.375 | 0.500 | 0.625 | 0.750 | ||||||
| 6 | 6.625 | 0.280 | 0.280 | 0.432 | 0.432 | 0.562 | 0.719 | 0.864 | ||||||
| 8 | 8.625 | 0.250 | 0.277 | 0.322 | 0.322 | 0.406 | 0.500 | 0.500 | 0.594 | 0.719 | 0.812 | 0.906 | 0.875 | |
| 10 | 10.750 | 0.250 | 0.307 | 0.365 | 0.365 | 0.500 | 0.500 | 0.594 | 0.719 | 0.844 | 1.000 | 1.125 | 1.000 | |
| 12 | 12.750 | 0.250 | 0.330 | 0.375 | 0.406 | 0.562 | 0.500 | 0.688 | 0.844 | 1.000 | 1.125 | 1.312 | 1.000 | |
| 14 | 14.000 | 0.250 | 0.312 | 0.375 | 0.375 | 0.438 | 0.594 | 0.500 | 0.750 | 0.938 | 1.094 | 1.250 | 1.406 | |
| 16 | 16.000 | 0.250 | 0.312 | 0.375 | 0.375 | 0.500 | 0.656 | 0.500 | 0.844 | 1.031 | 1.219 | 1.438 | 1.594 | |
| 18 | 18.000 | 0.250 | 0.312 | 0.438 | 0.375 | 0.562 | 0.750 | 0.500 | 0.938 | 1.156 | 1.375 | 1.562 | 1.781 | |
| 20 | 20.000 | 0.250 | 0.375 | 0.500 | 0.375 | 0.594 | 0.812 | 0.500 | 1.031 | 1.281 | 1.500 | 1.750 | 1.969 | |
| 22 | 22.000 | 0.250 | 0.375 | 0.500 | 0.375 | 0.875 | 0.500 | 1.125 | 1.375 | 1.625 | 1.875 | 2.125 | ||
| 24 | 24.000 | 0.250 | 0.375 | 0.562 | 0.375 | 0.688 | 0.969 | 0.500 | 1.219 | 1.531 | 1.812 | 2.062 | 2.344 | |
| 30 | 30.000 | 0.312 | 0.500 | 0.625 | 0.375 | 0.500 | ||||||||
| 32 | 32.000 | 0.312 | 0.500 | 0.625 | 0.375 | 0.688 | ||||||||
| 34 | 34.000 | 0.312 | 0.500 | 0.625 | 0.375 | 0.688 | ||||||||
| 36 | 36.000 | 0.312 | 0.500 | 0.625 | 0.375 | 0.750 | ||||||||
| 42 | 42.000 | 0.500 | 0.625 | 0.375 | 0.750 | |||||||||
Samuel Steel is a leading supplier of high-quality Carbon Steel API X56 5L PSL 2 Pipes products in Abuja, Nigeria. We focus on steel solutions and offer a variety of products. This includes Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our products are Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. We are known for our good delivery and excellent customer care. We aim to provide strong and durable steel materials for many industrial uses. We work hard to meet high standards, making us a trusted partner for your steel needs.
Carbon Steel API X56 5L PSL 2 Pipes find a lot of usages in various industries that, among other things, require tough and long-lasting piping systems for the transfer of fluids and gases. Also worth mentioning are the oil and gas transmission lines, petrochemical facilities, and offshore drilling operations where these pipes have proven their worth because of their capability to withstand high pressure and corrosion. They contribute to the safety and efficiency of flow management in power generation and water treatment plants as well. Besides, they are being used in construction and machinery where strength and trustworthiness are the main considerations. Their outstanding capabilities under extreme conditions have made them the most attractive option for the execution of critical energy and infrastructure projects.
Samuel Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Abuja, Nigeria.
