Noah Tubefittings, a leading manufacturer and supplier located in Kinshasa, Congo, offers top-notch Carbon Steel JIS G3445 Pipes that comply with international standards for both mechanical and structural applications. These pipes are crafted to deliver outstanding performance when transporting fluids and gases, as well as for use in machinery and automotive components. Utilizing cutting-edge manufacturing techniques, JIS G3445 pipes guarantee high precision, dimensional accuracy, and long-lasting durability. With their smooth surface finish, sturdy construction, and excellent machinability, they are perfect for a variety of engineering and industrial applications, ensuring reliability and a long service life even in tough conditions.
The Carbon Steel JIS G3445 Pipes are primarily made from carbon steel, with carefully controlled amounts of manganese, phosphorus, sulfur, and silicon to boost their strength and hardness. They boast a tensile strength ranging from 400 to 550 MPa and a yield strength of at least 245 MPa, along with impressive elongation and impact resistance. The uniform structure and fine grain characteristics of the material provide excellent formability and weldability. These pipes maintain their dimensions even under high pressure and temperature, making them ideal for mechanical systems and fluid transport.
| Standard | : | JIS G3445 |
| Description Name | : | STKM 11A Steel tube, STKM 12A steel tubes, STKM 12C steel tubes, STKM 13A steel tubes, STKM 13C steel tubes |
| Size | : | 6mm-340mm |
| Wall Thickness | : | 1mm-50mm |
| Shape | : | Round |
| Production Type | : | Cold drawn, cold rolled or hot rolled |
| Length | : | Single random length/ Double random length or as customer’s actual request max length is 10m |
| Grade | : | STKM 11A, STKM 12A, STKM 12C, STKM 12B, STKM 13A, STKM 13B, STKM 13C, STKM 15A, STKM 17A |
| C | Si | Mn | P | S |
| max 0.12 | max 0.35 | max 0.6 | max 0.04 | max 0.04 |
| Assortment | Yield point or Proof stress | Tensile strength | Elongation | Reduction of area | Charpy impact strength |
| – | N/mm 2 | N/mm 2 | % | % | J/cm 2 |
| Tubes | 290 | 35 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Samuel Steels, located in Abuja, Nigeria, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Carbon Steel JIS G3445 Pipes. These pipes are crafted for strength, precision, and durability, adhering to Japanese Industrial Standards (JIS) to guarantee outstanding dimensional accuracy and performance. Samuel Steels provides JIS G3445 Pipes that cater to the rigorous demands of mechanical, structural, and industrial applications. Thanks to cutting-edge manufacturing technology and strict quality control measures, the company delivers pipes that boast excellent weldability, toughness, and stress resistance, making them perfect for the automotive, machinery, and general engineering sectors.
| Permissible Specified Outside Diameter and Specified Wall Thickness | ||
| Specified Outside Diameter D mm (in.) | Specified Wall Thickness t mm (in.) | |
| Special Light Sizes a | Regular Sizes | |
| ≥ 10.3 (0.405) to < 13.7 (0.540) | — | ≥ 1.7 (0.068) to ≤ 2.4 (0.094) |
| ≥ 13.7 (0.540) to < 17.1 (0.675) | — | ≥ 2.2 (0.088) to ≤ 3.0 (0.118) |
| ≥ 17.1 (0.675) to < 21.3 (0.840) | — | ≥ 2.3 (0.091) to ≤ 3.2 (0.125) |
| ≥ 21.3 (0.840) to < 26.7 (1.050) | — | ≥ 2.1 (0.083) to ≤ 7.5 (0.294) |
| ≥ 26.7 (1.050) to < 33.4 (1.315) | — | ≥ 2.1 (0.083) to ≤ 7.8 (0.308) |
| ≥ 33.4 (1.315) to < 48.3 (1.900) | — | ≥ 2.1 (0.083) to ≤ 10.0 (0.394) |
| ≥ 48.3 (1.900) to < 60.3 (2.375) | — | ≥ 2.1 (0.083) to ≤ 12.5 (0.492) |
| ≥ 60.3 (2.375) to < 73.0 (2.875) | ≥ 2.1 (0.083) to ≤ 3.6 (0.141) | > 3.6 (0.141) to ≤ 14.2 (0.559) |
| ≥ 73.0 (2.875) to < 88.9 (3.500) | ≥ 2.1 (0.083) to ≤ 3.6 (0.141) | > 3.6 (0.141) to ≤ 20.0 (0.787) |
| ≥ 88.9 (3.500) to < 101.6 (4.000) | ≥ 2.1 (0.083) to ≤ 4.0 (0.156) | > 4.0 (0.156) to ≤ 22.0 (0.866) |
| ≥ 101.6 (4.000) to < 168.3 (6.625) | ≥ 2.1 (0.083) to ≤ 4.0 (0.156) | > 4.0 (0.156) to ≤ 25.0 (0.984) |
| ≥ 168.3 (6.625) to < 219.1 (8.625) | ≥ 2.1 (0.083) to ≤ 4.0 (0.156) | > 4.0 (0.156) to ≤ 40.0 (1.575) |
| ≥ 219.1 (8.625) to < 273.1 (10.750) | ≥ 3.2 (0.125) to ≤ 4.0 (0.156) | > 4.0 (0.156) to ≤ 40.0 (1.575) |
| ≥ 273.1 (10.750) to < 323.9 (12.750) | ≥ 3.6 (0.141) to ≤ 5.2 (0.203) | > 5.2 (0.203) to ≤ 45.0 (1.771) |
| ≥ 323.9 (12.750) to < 355.6 (14.000) | ≥ 4.0 (0.156) to ≤ 5.6 (0.219) | > 5.6 (0.219) to ≤ 45.0 (1.771) |
| ≥ 355.6 (14.000) to < 457 (18.000) | ≥ 4.5 (0.177) to ≤ 7.1 (0.281) | > 7.1 (0.281) to ≤ 45.0 (1.771) |
| ≥ 457 (18.000) to < 559 (22.000) | ≥ 4.8 (0.188) to ≤ 7.1 (0.281) | > 7.1 (0.281) to ≤ 45.0 (1.771) |
| ≥ 559 (22.000) to < 711 (28.000) | ≥ 5.6 (0.219) to ≤ 7.1 (0.281) | > 7.1 (0.281) to ≤ 45.0 (1.771) |
| ≥ 711 (28.000) to < 864 (34.000) | ≥ 5.6 (0.219) to ≤ 7.1 (0.281) | > 7.1 (0.281) to ≤ 52.0 (2.050) |
| ≥ 864 (34.000) to < 965 (38.000) | — | ≥ 5.6 (0.219) to ≤ 52.0 (2.050) |
| ≥ 965 (38.000) to < 1422 (56.000) | — | ≥ 6.4 (0.250) to ≤ 52.0 (2.050) |
| ≥ 1422 (56.000) to < 1829 (72.000) | — | ≥ 9.5 (0.375) to ≤ 52.0 (2.050) |
| ≥ 1829 (72.000) to < 2134 (84.000) | — | ≥ 10.3 (0.406) to ≤ 52.0 (2.050) |
You’ll find Carbon Steel JIS G3445 Pipes widely used in automotive parts, mechanical structures, hydraulic systems, and industrial machinery. They’re also employed in conveyor systems, frames, and other structural applications that require strong yet workable materials. Thanks to their remarkable mechanical strength and resistance to corrosion, they are well-suited for high-stress and vibration-prone applications. Their versatility and reliable performance make these pipes a go-to choice in the manufacturing, fabrication, and engineering sectors across various industries.
Samuel Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Abuja, Nigeria.
