Samuel Steel, headquartered in Abuja, Nigeria, stands out as a leading manufacturer and supplier of EN 9 sheets and plates. Renowned for delivering premium-quality carbon steel products, the company caters to a broad range of industrial applications. With a strong commitment to quality, precision, and customer satisfaction, Samuel Steel ensures that every EN 9 steel product adheres to international standards. Supported by modern infrastructure and a skilled technical team, the company provides high-performance steel solutions for the automotive, engineering, and construction sectors. Known for strength, reliability, and machinability, Samuel Steel is a trusted choice in both domestic and global markets.
EN 9 sheets and plates are made from medium carbon steel, typically containing 0.50–0.60% carbon and 0.50–0.80% manganese, offering an excellent balance of strength and wear resistance. These plates exhibit a tensile strength between 600–800 MPa, with good hardness and moderate ductility. EN 9 steel responds well to heat treatment processes such as hardening and tempering, which enhance its mechanical properties. It also offers good machinability when normalized or annealed. This combination of strength, toughness, and workability makes EN 9 steel ideal for components subjected to high mechanical stress and repetitive loading.
Grade : EN9 Low Alloy Steel Plate
Thickness : from 3mm up to as thick as 150mm
Length :3000mm-18000mm
Supply Condition : As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested : -52° C
Process of Manufacturing : Hot-Rolled (HR)
| Â Grade | Cr | C | Ni | Si | S | Mn | P | Mo |
| EN – 9 | – | .50 – .60 | – | .05 – .35 | .040 MAX | .50 – .80 | .040 MAX | – |
| Heat Treatment | Condition Tons/SQ.inch | Tensile Stress RE MPA | RP0.2 MPA | A min on 5.65so | Impac | Hardness HB | Limited Ruling Section mm | |
| IZODFT.L.b | KCV Joules | |||||||
| Normalise | 45 | 700 | – | 12 | – | – | 201-255 | 63 |
| 39 | 600 | – | 13 | – | – | 170/223 | 250 | |
| R | 45/55 | 700/850 | 385 | 14 | – | – | 201/277 | 100 |
| S | 50/60 | 775/925 | 450 | 14 | – | – | 223/277 | 63 |
| T | 55/65 | 850/1000 | 555 | 12 | – | – | 248/302 | 19 |
| BS 970 1991 | BS 970 1955 EN | AISI/SAE | Werkstoff |
| 070M55 | EN9 | 1055 | 1.0535 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
EN 9 sheets and plates are widely utilized in industries demanding durable and wear-resistant materials. In the automotive sector, they are used for shafts, gears, axles, and crankshafts. In engineering, EN 9 is employed in spindles, couplings, levers, and heavy-duty fasteners. The material’s ability to maintain hardness and toughness after heat treatment makes it ideal for machinery parts, tools, and structural components exposed to repeated stress. It is also used in agricultural and mining equipment due to its durability and strength. With outstanding versatility and mechanical performance, EN 9 steel remains a preferred choice for high-load, precision applications.
Samuel Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Abuja, Nigeria.
