Samuel Steels, located in Abuja, Nigeria, has earned a solid reputation as a reliable manufacturer and supplier of SA 515 Grade 60 Sheets and Plates, celebrated for their exceptional quality and durability. These carbon steel plates are tailor-made for pressure vessel applications, boasting impressive weldability, formability, and strength at high temperatures. Samuel Steels guarantees that each sheet and plate adheres to international standards, making them perfect for industries that prioritize performance, reliability, and longevity. With cutting-edge manufacturing technology and rigorous quality control, the company efficiently delivers products that meet a wide range of industrial needs.
SA 515 Grade 60 Sheets and Plates are primarily made up of carbon, manganese, phosphorus, sulfur, and silicon, which endow them with remarkable mechanical and thermal properties. They feature a minimum tensile strength of about 415 MPa and a yield strength of 220 MPa, ensuring they resist deformation even under high pressure. These plates also demonstrate good ductility and toughness, making fabrication and welding a breeze. Their fine grain structure enhances resistance to cracking and corrosion, making them ideal for use in boilers and pressure vessels that operate at elevated temperatures.
| Specifications | ASTM A515 Gr. 60 / ASME A515 Grade 60 | |
| Thickness |
|
|
| Length | 3000 mm – 8000 mm | |
| Width | 1500-3500mm | |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) | |
| Finish | Cold rolled sheet (CR), Hot rolled plate (HR) | |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C | Mn | P | S | Si |
|---|---|---|---|---|---|
| A515 Grade 60 | 0.24-0.31 | 0.98 max | 0.035 max | 0.035 max | 0.13-0.45 |
| Grade | Thickness | Yield | Tensile | Elongation |
|---|---|---|---|---|
| A515 Grade 60 | 50-200mm | MPa -220 min | MPa – 415-550 | 21-25% |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
You’ll find SA 515 Grade 60 Sheets and Plates commonly used in the construction of boilers, heat exchangers, pressure vessels, and storage tanks across various sectors, including petrochemical, power generation, oil and gas, and chemical processing. Their ability to endure high pressure and temperature conditions makes them a go-to choice for critical structural applications. Additionally, they are utilized in refineries and thermal plants for crafting components that demand high strength and stability. The material’s versatility, strength, and durability make it a top pick for engineers and manufacturers around the globe.
