Samuel Steels stands out as a top manufacturer and supplier in Abuja, Nigeria, offering high-quality Carbon Steel A192 Tubing that’s perfect for high-pressure applications and boasts impressive heat transfer capabilities. These tubes are crafted to meet ASTM A192 standards, ensuring they deliver exceptional quality, precision, and reliability. Renowned for their high tensile strength, durability, and resistance to corrosion and scaling, A192 Tubes find their place in boilers, heat exchangers, and condensers. Samuel Steels prioritizes strict dimensional accuracy and a flawless surface finish, providing customers with trustworthy tubing solutions that are ideal for power generation, petrochemical, and industrial heat transfer systems.
Carbon Steel A192 Tubing is made up of carbon (0.06–0.18%), manganese (0.27–0.63%), phosphorus (0.035% max), sulfur (0.035% max), and trace amounts of silicon. This blend enhances the tubing’s strength, ductility, and thermal conductivity. The tubes showcase a minimum tensile strength of 325 MPa, a yield strength of 180 MPa, and an elongation of 35%. They are designed to resist high temperatures and pressure, maintaining their structural integrity in steam and boiler systems. A192 Tubes also feature smooth internal surfaces that promote efficient heat transfer and offer excellent corrosion resistance under thermal stress.
| Craft | Cold rolled and Cold drawn |
| Standards | ASTM, ASME and API |
| Length | Min 3 Meters, Max18 Meters, or according to customer’s requirement |
| Thickness | 3-12mm |
| Schedules | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| Type | Seamless / ERW / Welded / Fabricated |
| Tolerance | Cold drawn pipe: +/-0.1mm
Cold rolled pipe: +/-0.05mm |
| Additional Testing | NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| Form | Round, Hydraulic Etc |
| Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
| End | Plain End, Beveled End, Treaded |
| Specialized in | Large Diameter ASTM A192 Pipe |
| Size | 1/2” NB to 36” NB |
|
C, % |
Mn, % |
Si, % |
P, % |
S, % |
|
0.06-0.18 |
0.27-0.63 |
0.25 max |
0.035 max |
0.035 max |
|
Tensile Strength , MPa |
Yield Strength , MPa |
Elongation, % |
Hardness, HB, WT≥5.1mm |
Hardness, HRB, WT＜5.1mm |
|
325 min |
180 min |
35 min |
137 max |
77 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a leading manufacturer and distributor of high-quality Carbon Steel A192 Tubing in Abuja, Nigeria. We offer premium steel materials and a diverse range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to fast delivery and exceptional customer service, we source top-grade raw materials to ensure superior strength and durability for demanding industrial applications. Contact us today for all your Carbon Steel A192 Tubing needs!
|
Hot rolled |
Outside Diameter, mm |
Tolerance, mm |
|
OD≤101.6 |
+0.4/-0.8 |
|
|
101.6＜OD≤177.8 |
+0.4/-1.2 |
|
|
Cold Drawn |
Outside Diameter, mm |
Tolerance, mm |
|
OD＜25.4 |
±0.10 |
|
|
25.4≤OD≤38.1 |
±0.15 |
|
|
38.1＜OD＜50.8 |
±0.20 |
|
|
50.8≤OD＜63.5 |
±0.25 |
|
|
63.5≤OD＜76.2 |
±0.30 |
|
|
76.2≤OD≤101.6 |
±0.38 |
|
|
101.6＜OD≤177.8 |
+0.38/-0.64 |
|
|
Hot rolled
|
Outside Diameter, mm |
Tolerance, % |
|
OD≤101.6, WT≤2.4 |
+40/-0 |
|
|
OD≤101.6, 2.4＜WT≤3.8 |
+35/-0 |
|
|
OD≤101.6, 3.8＜WT≤4.6 |
+33/-0 |
|
|
OD≤101.6, WT>4.6 |
+28/-0 |
|
|
OD>101.6, 2.4＜WT≤3.8 |
+35/-0 |
|
|
OD>101.6, 3.8＜WT≤4.6 |
+33/-0 |
|
|
OD>101.6, WT>4.6 |
+28/-0 |
|
|
Cold Drawn
|
Outside Diameter, mm |
Tolerance, % |
|
OD≤38.1 |
+20/-0 |
|
|
OD>38.1 |
+22/-0 |
Carbon Steel A192 Tubing is made up of carbon (0.06–0.18%), manganese (0.27–0.63%), phosphorus (0.035% max), sulfur (0.035% max), and trace amounts of silicon. This blend enhances the tubing’s strength, ductility, and thermal conductivity. The tubes showcase a minimum tensile strength of 325 MPa, a yield strength of 180 MPa, and an elongation of 35%. They are designed to resist high temperatures and pressure, maintaining their structural integrity in steam and boiler systems. A192 Tubes also feature smooth internal surfaces that promote efficient heat transfer and offer excellent corrosion resistance under thermal stress.
Samuel Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Abuja, Nigeria.
