Benjamin Tubefittings is a recognized manufacturer and supplier of high-quality Carbon Steel BS 3601 Pipes in Abuja, Nigeria. These pipes are manufactured in compliance with the British Standard BS 3601, ensuring reliable performance in pressure-bearing and structural piping applications. Our Carbon Steel BS 3601 Pipes are known for their durability, dimensional accuracy, and excellent mechanical strength, making them suitable for demanding operational environments. They are widely used in industries that require safe and efficient fluid or gas transmission. Each pipe undergoes strict inspection and testing to guarantee quality, leak-proof performance, and long service life under various temperature and pressure conditions.
Carbon Steel BS 3601 Pipes typically contain carbon, manganese, silicon, sulfur, and phosphorus in controlled proportions. The balanced carbon content gives these pipes excellent tensile strength and hardness, while manganese improves toughness and wear resistance. Silicon helps maintain stability under heat, and low sulfur and phosphorus levels ensure good weldability and reduced brittleness. These pipes exhibit high yield and tensile strength, reliable ductility, and strong impact resistance. Their mechanical properties allow them to withstand internal pressure, thermal stress, and mechanical loads, making them suitable for both industrial fluid transfer and structural applications.
| Dimensions | ASTM, ASME and API |
| Thickness | 50mm to 7.00mm, custom OD and thickness available on request |
| End | Plain End, Beveled End, Treaded |
| Length | Single Random, Double Random & Required Length, Custom Size – according to customer’s requirement |
| Schedules | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| Types | Seamless / ERW / Welded / Fabricated / CDW |
| Outer Diameter | 19.05mm to 127mm |
| Wall Thickness | 0.8mm to 6.0mm |
| Length | 6mtr/ 12mtr or Cut to Length |
| Capacity | 7000 Mt/Month |
Grade | Mfg. Process | Chemical Composition(%) | ||||||||
C | Si | Mn | P | S | Ni | Cr | Mo | Others | ||
BW320 | B | 0.16Max | – | 0.30~0.70 | 0.040Max | 0.040Max | – | – | – | – |
ERW320 | E | 0.16Max | – | 0.30~0.70 | 0.040Max | 0.040Max | – | – | – | – |
ERW360 | E | 0.17Max | 0.35Max | 0.40~0.80 | 0.040Max | 0.050Max | – | – | – | – |
ERW430 | E | 0.21Max | 0.35Max | 0.40~1.20 | 0.040Max | 0.040Max | – | – | – | – |
S360 | S | 0.17Max | 0.35Max | 0.40~0.80 | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
S430 | S | 0.21Max | 0.35Max | 0.40~1.20 | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
SAW430 | A | 0.25Max | 0.50Max | 1.20Max | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
|
Grade
|
Tensile Test MPa or N/mm2 |
Remaks (Similar to JIS) |
Possibility Temperature |
|
|
Min Yield point |
Tensile Strength |
|||
|
BW320 |
195 |
320~460 |
– |
|
|
ERW320 |
195 |
320~460 |
– |
|
|
ERW360 |
235 |
360~500 |
(STPG370) |
|
|
ERW430 |
195 |
430~570 |
(STPG410) |
|
|
S360 |
235
225
215 |
360~550 |
(STPG310) |
|
|
S430 |
275
265
255 |
430~570 |
(STPG410) |
|
|
SAW430 |
275
265
255 |
430~570 |
(STPY400) |
|
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Nominal Pipe Size (inches) | Outer Diameter (mm) | Wall Thickness (mm) | Weight (kg/m) |
|---|---|---|---|
| 1/2 | 21.3 | 2.11 | 1.21 |
| 3/4 | 26.7 | 2.11 | 1.62 |
| 1 | 33.4 | 2.77 | 2.49 |
| 1 1/4 | 42.2 | 3.56 | 3.74 |
| 1 1/2 | 48.3 | 3.68 | 4.46 |
| 2 | 60.3 | 3.91 | 5.71 |
| 3 | 88.9 | 5.49 | 11.29 |
| 4 | 114.3 | 6.02 | 16.07 |
| 6 | 168.3 | 7.11 | 28.26 |
Jaxon Steel is a leading manufacturer and exporter of high-quality Carbon Steel BS3601 Pipes in Abuja, Nigeria. We offer a comprehensive range of steel solutions, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product portfolio includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliability and outstanding customer service, we are dedicated to delivering top-tier steel products designed for demanding industrial applications, ensuring long-lasting durability and superior performance. Jaxon Steel is your trusted partner for all Carbon Steel BS3601 Pipe needs.
Carbon Steel BS 3601 Pipes are extensively used for conveying water, oil, gas, steam, and compressed air in industrial systems. They are commonly installed in petroleum refineries, boiler plants, chemical industries, water supply networks, HVAC systems, and mechanical fabrication setups. Their high strength and reliability make them ideal for structural and pressure-bearing applications, including power plant piping frameworks, fire-fighting pipelines, and marine engineering systems. These pipes perform efficiently in high-temperature and high-pressure environments while maintaining integrity and safety. Their versatility and durability make Carbon Steel BS 3601 Pipes a preferred choice for critical industrial and infrastructure projects.
