Samuel Steels stands out as a reliable manufacturer and supplier of Carbon Steel BS 3606 Pipes in Abuja, Nigeria. They provide precision-engineered piping solutions that adhere to British Standard specifications. These pipes are crafted for mechanical, hydraulic, and fluid transmission systems, where strength, reliability, and resistance to corrosion are essential. With rigorous quality control in place, Carbon Steel BS 3606 Pipes guarantee dimensional accuracy, smooth internal surfaces, and consistent mechanical performance. Samuel Steels caters to various industries, including oil and gas, petrochemical, power generation, and water treatment, making these pipes perfect for low- and medium-pressure applications in demanding industrial settings.
Carbon Steel BS 3606 Pipes primarily consist of carbon (0.17–0.25%), manganese (0.30–1.20%), silicon (0.10–0.35%), phosphorus (0.035% max), and sulfur (0.035% max), with iron making up the remainder. These pipes exhibit a tensile strength between 410–530 MPa and a yield strength of about 235 MPa. They also provide good elongation (around 20%) and exceptional ductility, which makes them easy to fabricate and weld. The material’s mechanical strength and toughness ensure dependable performance under pressure, vibration, and fluctuating temperature conditions in various industrial systems.
| Dimensions | ASTM, ASME and API |
| Thickness | 50mm to 7.00mm, custom OD and thickness available on request |
| End | Plain End, Beveled End, Treaded |
| Length | Single Random, Double Random & Required Length, Custom Size – according to customer’s requirement |
| Schedules | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| Types | Seamless / ERW / Welded / Fabricated / CDW |
| Outer Diameter | 19.05mm to 127mm |
| Wall Thickness | 0.8mm to 6.0mm |
| Length | 6mtr/ 12mtr or Cut to Length |
| Capacity | 7000 Mt/Month |
|
Grade |
Mfg. Process |
Chemical Composition(%) | ||||||||
|
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Mo |
Others |
||
|
BW320 |
B |
0.16Max |
– |
0.30~0.70 |
0.040Max |
0.040Max |
– |
– |
– |
– |
|
ERW320 |
E |
0.16Max |
– |
0.30~0.70 |
0.040Max |
0.040Max |
– |
– |
– |
– |
|
ERW360 |
E |
0.17Max |
0.35Max |
0.40~0.80 |
0.040Max |
0.050Max |
– |
– |
– |
– |
|
ERW430 |
E |
0.21Max |
0.35Max |
0.40~1.20 |
0.040Max |
0.040Max |
– |
– |
– |
– |
|
S360 |
S |
0.17Max |
0.35Max |
0.40~0.80 |
0.040Max |
0.040Max |
– |
– |
– |
t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
|
S430 |
S |
0.21Max |
0.35Max |
0.40~1.20 |
0.040Max |
0.040Max |
– |
– |
– |
t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
|
SAW430 |
A |
0.25Max |
0.50Max |
1.20Max |
0.040Max |
0.040Max |
– |
– |
– |
t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
Grade
| Tensile Test MPa or N/mm2 | Remaks (Similar to JIS) | Possibility Temperature | |
Min Yield point | Tensile Strength | |||
BW320 | 195 | 320~460 | – | |
ERW320 | 195 | 320~460 | – | |
ERW360 | 235 | 360~500 | (STPG370) | |
ERW430 | 195 | 430~570 | (STPG410) | |
S360 | 235 225 215 | 360~550 | (STPG310) | |
S430 | 275 265 255 | 430~570 | (STPG410) | |
SAW430 | 275 265 255 | 430~570 | (STPY400) | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outer Diameter (OD) | Wall Thickness (WT) | Length |
|---|---|---|
| 6mm – 25mm | 1mm – 3mm | Up to 6 meters |
| 26mm – 50mm | 3mm – 6mm | Up to 9 meters |
| 51mm – 150mm | 6mm – 12mm | Up to 12 meters |
| 151mm – 300mm | 12mm – 25mm | Customizable |
| 301mm – 508mm | 25mm – 50mm | Customizable |
Jaxon Steel is a leading manufacturer and exporter of Carbon Steel BS3606 Pipes in Abuja, Nigeria. We offer a vast array of steel solutions, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our diverse product portfolio includes pipes, tubes, flanges, pipe fittings, forged fittings, sheets, and plates. We are the most trusted name for supplying critical industrial applications with superior-quality steel products, built on reliability and excellent service. Our BS3606 Pipes are hard-wearing and high-performance-efficient. Jaxon Steel is here to fulfill all your Carbon Steel BS3606 Pipe requirements.
Carbon Steel BS 3606 Pipes find their place in numerous industries for transporting fluids and gases under pressure. They’re frequently used in water supply systems, steam lines, oil and gas pipelines, hydraulic systems, and general mechanical engineering. In construction, these pipes serve structural and scaffolding purposes. Their strength and durability, along with their ability to handle moderate pressure, make them suitable for both above-ground and underground piping installations. Additionally, these pipes are utilized in process industries, refineries, and power plants, ensuring efficient flow, minimal leakage, and a long service life in demanding environments.
Samuel Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Abuja, Nigeria.
