Samuel Steels, located in Abuja, Nigeria, has built a solid reputation as a top-notch manufacturer and supplier of high-quality Carbon Steel WPHY 42 Pipe Fittings. These fittings are celebrated for their remarkable strength, durability, and precision engineering. They’re specifically crafted to ensure secure, leak-proof connections in piping systems that operate under high pressure and temperature. Samuel Steels employs cutting-edge fabrication techniques and strict quality control measures to meet international standards, guaranteeing long-lasting and reliable performance. The Carbon Steel WPHY 42 Pipe Fittings are perfect for demanding industries like oil and gas, petrochemical, power generation, and construction, thanks to their excellent resistance to stress and corrosion.
These fittings are primarily made up of carbon, manganese, phosphorus, sulfur, and silicon, with trace elements that enhance their mechanical stability. They boast a minimum yield strength of 290 MPa and a tensile strength of about 414 MPa, providing outstanding toughness and ductility. With excellent weldability and formability, they maintain their structural integrity even under fluctuating pressure and temperature conditions. Their chemical makeup offers good resistance to oxidation and deformation, ensuring reliable performance in challenging environments.
| Specifications | ASTM A860/ ASME SA860 |
|---|---|
| Grade | WPHY 42 |
| Dimension | ASME/ ANSI B16.9 | BS10 | ASME B16.28 | BS1560 | BS4504 | MSS-SP-43 |
| Thickness of Fittings | SCH 10, SCH20, SCH 30, STD SCH 40, SCH 60, XS, SCH80, SCH100, SCH 120, SCH 140, SCH160, XXS available with NACE MR 01-75 |
| Types | Seamless | Welded | Fabricated |
| Bending Radius | R= 1D, 8D, 3D, 2D, 6D, 5D, 10D |
| Size Range | ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) |
| Size Ranges | Seamless ButtWeld Fitting: From 1/2″ – 10″ Welded ButtWeld Fitting: From 1/2″ – 48″ |
| Process of Manufacturing | Push, Press, Cast, Forge. |
| Grade | P | Mn | S | Si | Ni | Cr | Mo | Cu | Ti | Cb | V | Al |
| WPHY42 | 1.00-1.45 | 0.20 | 0.03 | 0.01 | 0.15-0.40 | 0.50 | 0.30 | 0.25 | 0.35 | 0.10 | 0.05 | 0.04 |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 515-690 | 415 | 28 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Nominal Pipe Size | Outside Diameter | Caps | Straight Tees | Straight Crosses | Stub Ends | |||
| inch | mm | inch | Length (inch) | Center to End (inch) | Center to End (inch) | Lap Diameter (inch) | Long Length (inch) | Short Length (inch) |
| 1/2 | 21.3 | 0.840 | 1 | 1 | – | 1 3/8 | 3 | 2 |
| 3/4 | 26.7 | 1.050 | 1 | 1 1/8 | – | 1 11/16 | 3 | 2 |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 1/2 | 1 1/2 | 2 | 4 | 2 |
| 1 1/4 | 42.2 | 1.660 | 1 1/2 | 1 7/8 | 1 7/8 | 2 1/2 | 4 | 2 |
| 1 1/2 | 48.3 | 1.900 | 1 1/2 | 2 1/4 | 2 1/4 | 2 7/8 | 4 | 2 |
| 2 | 60.3 | 2.375 | 1 1/2 | 2 1/2 | 2 1/2 | 3 5/8 | 6 | 2 1/2 |
| 2 1/2 | 73.0 | 2.875 | 1 1/2 | 3 | 3 | 4 1/8 | 6 | 2 1/2 |
| 3 | 88.9 | 3.500 | 2 | 3 3/8 | 3 3/8 | 5 | 6 | 2 1/2 |
| 3 1/2 | 101.6 | 4.000 | 2 1/2 | 3 3/4 | 3 3/4 | 5 1/2 | 6 | 3 |
| 4 | 114.3 | 4.500 | 2 1/2 | 4 1/8 | 4 1/8 | 6 3/16 | 6 | 3 |
| 5 | 141.3 | 5.563 | 3 | 4 7/8 | 4 7/8 | 7 5/16 | 8 | 3 |
| 6 | 168.3 | 6.625 | 3 1/2 | 5 5/8 | 5 5/8 | 8 1/2 | 8 | 3 1/2 |
| 8 | 219.1 | 8.625 | 4 | 7 | 7 | 10 5/8 | 8 | 4 |
| 10 | 273.1 | 10.750 | 5 | 8 1/2 | 8 1/2 | 12 3/4 | 10 | 5 |
| 12 | 323.9 | 12.750 | 6 | 10 | 10 | 15 | 10 | 6 |
Made from carbon steel and incorporating elements like manganese, phosphorus, sulfur, and silicon, Carbon Steel WPHY 42 Pipe Fittings strike a perfect balance between strength and toughness. They feature a minimum yield strength of 42,000 psi (290 MPa) and can handle tensile strengths of up to 60,000 psi (415 MPa). With impressive impact resistance and ductility, these fittings are built to last, even under varying pressures and temperatures. Their consistent wall thickness and precise dimensions ensure seamless installation and reliable long-term performance.
These fittings find extensive use across various industries, including oil and gas, power generation, refineries, and chemical processing plants. They’re ideal for high-pressure pipeline systems, offshore platforms, and water supply networks. Essential for connecting, branching, and redirecting flow in piping systems, they maintain structural integrity and efficiency. Thanks to their robust construction and resistance to corrosion, Carbon Steel WPHY 42 Pipe Fittings are the go-to choice for critical applications that demand reliability and strength in tough operating conditions.
Samuel Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Abuja, Nigeria.
