Samuel Steels, a reputable manufacturer and supplier located in Abuja, Nigeria, specializes in high-quality SA 516 GR.60N NACE and HIC Plates that are built to meet the rigorous demands of pressure vessel and boiler applications. These plates are crafted for outstanding performance in environments prone to hydrogen-induced cracking (HIC) and sulfide stress corrosion cracking (SSC). Thanks to cutting-edge production technology and stringent quality control measures, Samuel Steels guarantees plates that boast excellent toughness, weldability, and corrosion resistance. The company caters to a variety of industries, including oil and gas, petrochemical, energy, and refining, providing durable and dependable steel solutions for essential operations.
SA 516 GR.60N NACE and HIC Plates are carbon steel plates that have been normalized to enhance their mechanical properties and are tested according to NACE MR0175/ISO 15156 standards. Their composition features carbon, manganese, phosphorus, sulfur, and silicon, which together ensure remarkable strength and resistance to cracking in wet hydrogen sulfide environments. These plates achieve a minimum tensile strength of 415–550 MPa and exhibit excellent notch toughness even at low temperatures. The HIC testing guarantees their reliability in sour service conditions, making them perfect for pressure vessels and boilers that operate in challenging environments.
| Grade | ASME SA 516 GR.60N Boiler and Pressure Vessel Steel Plates |
|---|---|
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | 52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service. |
| Process of Manufacturing | Hot-Rolled (HR) |
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.20 | 0.4 | 0.95/1.50 | 0.025 | 0.025 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength | Yield strength | Elongation min, % 200 mm (8 in) | Elongation min, % 50 mm (2 in) |
| 415-550 MPa | 250 MPa | 21 | 25 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-161-430A | EN10028 P265GH | A/SA516 – Grade 60 | DIN 17155 HII |
Jaxon Steel is a trusted manufacturer and supplier of high-quality SA 516 GR.60N NACE and HIC Plates​ in Abuja, Nigeria. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your SA 516 GR.60N NACE and HIC Plates​ needs!
You’ll find SA 516 GR.60N NACE and HIC Plates widely used in sectors like oil and gas refining, petrochemical processing, and power generation. They are particularly suited for fabricating pressure vessels, storage tanks, heat exchangers, and reactors that are exposed to hydrogen sulfide and corrosive media. Additionally, these plates are utilized in pipelines, separators, and offshore equipment that require enhanced resistance to HIC and SSC. Their superior weldability and mechanical strength make them the go-to choice for manufacturers looking for long-lasting, safe, and high-performance materials for critical industrial applications.
Samuel Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Abuja, Nigeria.
