Samuel Steel is one of the prime Carbon Steel EN 10025 Pipes manufacturer and supplier companies in Abuja, Nigeria. With a keen focus on quality and accuracy, Samuel Steel has a variety of customers from different industries. Their EN 10025 pipes have a reputation for high strength, toughness, and flexibility, which makes them a first-rate product in cases where high-performance material is needed. The company guarantees that every pipe is of international standards, ensuring that customers get consistent and dependable products. For construction, manufacturing, or for other industrial applications, Samuel Steel is a reliable source for steel supply companies.
Carbon Steel EN 10025 Pipes include grades S235JR, S275JR, and S355J2G3, all having unique composition and mechanical properties. For example, S235JR holds a maximum of 0.20% carbon, up to 1.60% manganese, and ≤0.55% silicon content, having a yield strength of 235 MPa and tensile strength ranging from 360–510 MPa. S275JR has a maximum of 0.25% carbon, up to 1.60% manganese, and ≤0.55% silicon, with a yield strength of 275 MPa and tensile strength ranging from 430–580 MPa. S355J2G3 has a maximum of 0.20% carbon, up to 1.60% manganese, and ≤0.55% silicon content and offers yield strength of 355 MPa and tensile strength of 490–630 MPa. The pipes go through heat treatment processes to develop desired mechanical properties, making them suitable for heavy-demand applications.
| Standard | AISI, DIN, EN, GB, IS, JIS, ASTM, ASME Pipe |
|---|---|
| Steel Grade En 10025 Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| EN 10025 Grade S355J2G3 Welded Pipe Size | 5.0 mm – 1219.2 mm |
| EN 10025 Gr S355J2G3 EFW Pipe size | 5.0 mm – 1219.2 mm |
| Steel En 10025-2-s235jr+ar Tube Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| En 10025 S235jr Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| En 10025 S275jr Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| Steel En 10025-2-s235jr+ar Welded Tube Size | 6.35 mm OD To 152 mm OD |
| En 10025-2 S275jr Steel Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| S235jr+c En 10025 Tube wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| S460ml En 10025-4 Carbon Steel Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| En 10025-3 S355nl Steel Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Din En 10025 W.1. 1.0577 Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| EN 10025 Grade S355J2G3 Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| En 10025-5 Corten End | Plain End, Beveled End, Treaded Pipe & Tube |
| Steel Grade En 10025 Marking | All En 10025 Mild Steel Pipes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| En 10025 Grade S355j2g3 CS Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| EN 10025 Gr S355J2G3 Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| En 10025 Grade S355j2g3 Carbon Steel Specialize in |
|
| Material Test Certificates (MTC) | Material Test Certificates (MTC) as per EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2, 100% Radiography Test Report, Raw Materials Certificate, Third Party Inspection Report, Fumigation Certificates, Heat Treatment Charts, Din En 10025 W.1. 1.0577 Pipe HS Code Commercial Invoice, Form A for Generalized System of Preferences (GSP) |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| max 0.20 | max 0.55 | max 1.60 | 0.035 | 0.035 | – | – | – | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 490 | 630 | – | – | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel EN 10025 Pipe products in Abuja, Nigeria. Specializing in premium steel materials, we offer a comprehensive range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to reliable delivery and exceptional customer service, Jaxon Steel ensures the supply of top-grade materials that deliver superior performance across various industrial applications. Trust Jaxon Steel for all your Carbon Steel EN 10025 Pipe needs.
| 1/8″ IPS(.405″ O.D.) | 3 1/2″ IPS( 4.000″ O.D.) |
|---|---|
| SCH 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/4″ IPS(.540″ O.D.) | 4″ IPS(4.500″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 3/8″ IPS(.675″ O.D.) | 5″ IPS( 5.563″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/2″ IPS(.840″ O.D.) | 6″ IPS(6.625″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 3/4″ IPS(1.050″ O.D.) | 8 ” IPS(8.625″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 1″ IPS:(1.315′ O.D.) | 10″ IPS(10.750″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 1-1/4″ IPS(1.660″ O.D.) | 12″ IPS(12.750″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
| 1-1/2″ IPS(1.900″ O.D.) | 14″ IPS(14.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10 (.188), SCH40 (.375) |
| 2″ IPS(2.375″ O.D.) | 16″ IPS(16.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10(.188), SCH40(.375) |
| 2 1/2″ IPS(2.875″ O.D.) | 18″ IPS (18.000″ O.D.) |
| DIN | EN | BS | NFA | ASTM | ASME |
|---|---|---|---|---|---|
| DIN 23932)/23942) Grade St 52-3 | EN 10025 Grade S355J2G3 | NFA A 49-643 Grade TS 47 2 | – | – | – |
Carbon Steel EN 10025 Pipes find extensive use across many industries because of their strong mechanical properties. They find widespread application in the production of structural parts, bridges, and buildings with high strength and durability needs. Their durability and resistance to wear and tear coupled with their ability to withstand high-stress applications make them suitable for use in construction, automotive, and machinery industries. Their high machinability also helps in easy fabrication, making them a favorite among precision engineering applications.
Samuel Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Abuja, Nigeria.
