Samuel Steels, a trusted manufacturer and supplier based in Abuja, Nigeria, is well-known for producing high-quality Carbon Steel EN 10297-1 Pipes that ensure exceptional performance, durability, and precision. These seamless pipes are designed to meet international standards, making them ideal for use in high-pressure and high-temperature environments. Samuel Steels manufactures each pipe with strict quality control to guarantee excellent strength, surface finish, and corrosion resistance. Their EN 10297-1 pipes are widely used in engineering, oil and gas, and mechanical applications where reliability and long-lasting performance are essential.
Carbon Steel EN 10297-1 Pipes are made from premium-grade carbon steel containing about 0.17–0.23% carbon, 0.30–1.20% manganese, and small amounts of silicon, sulfur, and phosphorus. This composition offers excellent mechanical strength, good weldability, and resistance to stress and deformation. Mechanically, these pipes provide a tensile strength of approximately 490–630 MPa and yield strength around 280–350 MPa, along with good elongation and toughness. Their fine-grained structure enhances durability and performance under high pressure and temperature conditions.
| Yield Strength | Tensile Strength | Elongation A5 min | |||
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 490 | – | – | 20 | ||
| Minimum mechanical properties | ||||||||||||
| Pipe type | Steel grades | Delivery condition | Upper yield limit Re MPa | Tensile strength Rm MPa | Elongation A% | |||||||
| Seamless circular steel tubes for mechanical and general engineering purposes E235, E275, E355, According to PN-EN 10297-1 | For T in mm | For T in mm | 1 | t | ||||||||
| <\= 16 | >16 <\=40 | >40 <\=65 | >65 <\=80 | >80 <\=100 | <\=16 | >16 <\=40 | >40 <\=65 | |||||
| E235 | +A lub+N | 235 | 215 | 205 | 195 | 360 | 360 | 360 | 340 | 340 | 25 | |
| E275 | +A lub+N | 275 | 255 | 245 | 235 | 410 | 410 | 410 | 380 | 380 | 22 | |
| E355 | +A lub+N | 354 | 345 | 315 | 295 | 490 | 490 | 410 | 470 | 470 | 20 | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel EN 10297-1 Pipe products in Abuja, Nigeria. Specializing in premium steel materials, we offer a diverse range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong commitment to timely delivery and exceptional customer service, Jaxon Steel ensures the supply of top-grade materials that deliver superior performance in various industrial applications. Trust Jaxon Steel for all your Carbon Steel EN 10297-1 Pipe needs.
| 1/8″ IPS(.405″ O.D.) | 3 1/2″ IPS( 4.000″ O.D.) |
|---|---|
| SCH 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/4″ IPS(.540″ O.D.) | 4″ IPS(4.500″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 3/8″ IPS(.675″ O.D.) | 5″ IPS( 5.563″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/2″ IPS(.840″ O.D.) | 6″ IPS(6.625″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 3/4″ IPS(1.050″ O.D.) | 8 ” IPS(8.625″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 1″ IPS:(1.315′ O.D.) | 10″ IPS(10.750″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 1-1/4″ IPS(1.660″ O.D.) | 12″ IPS(12.750″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
| 1-1/2″ IPS(1.900″ O.D.) | 14″ IPS(14.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10 (.188), SCH40 (.375) |
| 2″ IPS(2.375″ O.D.) | 16″ IPS(16.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10(.188), SCH40(.375) |
| 2 1/2″ IPS(2.875″ O.D.) | 18″ IPS (18.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH-40 (.375) |
| 3″ IPS( 3.500″ O.D.) | |
| SCH 5, 10, 40, 80, 160, XXH |
Carbon Steel EN 10297-1 Pipes are widely used in power generation, oil and gas refineries, chemical industries, and mechanical systems. They are ideal for applications such as conveying fluids, structural frameworks, and high-temperature services. These pipes are also used in boilers, heat exchangers, and hydraulic systems due to their ability to handle stress, corrosion, and vibration effectively. Their excellent strength, dimensional accuracy, and longevity make them a preferred choice for modern industrial and engineering applications.
Samuel Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Abuja, Nigeria.
