Meet Samuel Steels, a well-respected manufacturer and supplier located in Abuja, Nigeria. They specialize in top-notch ARCELOR 450 Sheets and Plates, crafted for outstanding strength, hardness, and wear resistance. These plates are built to thrive in tough and abrasive conditions, thanks to advanced steelmaking techniques that guarantee consistency, durability, and impressive mechanical performance. ARCELOR 450 is a high-strength, abrasion-resistant grade perfect for industries that need long-lasting materials with minimal maintenance. With precise dimensions and customizable options, Samuel Steels provides ARCELOR 450 Sheets and Plates to various sectors, including mining, construction, material handling, and heavy equipment manufacturing
The ARCELOR 450 Sheets and Plates are primarily made up of carbon, manganese, silicon, chromium, nickel, and molybdenum, creating a fantastic balance of strength and toughness. They boast a nominal hardness of around 450 HBW and a tensile strength ranging from 1250 to 1450 MPa. These plates are known for their exceptional impact resistance, weldability, and formability, even in the harshest working conditions. Their robust microstructure ensures remarkable resistance to abrasion and mechanical wear, making ARCELOR 450 the go-to choice for heavy-duty applications that require durability and performance under constant stress and impact.
Item: ARCELOR 450
Thickness : 5mm to 150mm
Length : 6,000mm to 12,000mm
Width : 1,500mm to 2,500mm
Heat Treatment: N, Q+T
Surface Point : EP, PE, HDP, SMP, PVDF
| Plate Thickness MM | %C Max | %Mn Max | %P Max | %S Max | %SI Max | %Cr Max | %Ni Max | %Mo Max | B Max | CE Max | PCM Max |
| 6.0 – 20.0 | 0.52 | 0.34 | |||||||||
| 21.0 – 40.0 | 0.30 | 1.60 | 0.025 | 0.010 | 0.70 | 1.00 | 0.60 | 0.60 | 0.040 | 0.60 | 0.40 |
| 41.0 – 50.0 | 0.65 | 0.50 |
| Â | Hardness HBW | Typical yield strength MPa, |
| mm | (min – max 1) | not guaranteed |
| 3 – 80 | 425 – 475 | 1100 – 1300 |
| (80) – 100 | 410 – 475 | 1050 – 1300 |
| (100) – 130 | 390 – 475 | 1000 – 1300 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1/8″ | 3/8″ | 3/4″ | 1-1/2″ | 3″ |
| 3/16″ | 1/2″ | 1″ | 2″ | 4″ |
| 1/4″ | 5/8″ | 1-1/4″ | 2-1/2″ | Â |
| *1/8″ thick plate is available in one size only 60″x 120″. The 3/6″ thick plate is available only as 48″ x 144″ and 96″ x 144″. | ||||
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
ARCELOR 450 Sheets and Plates find their place in a variety of applications that require top-notch abrasion and impact resistance. They’re commonly used in mining equipment, earthmoving machinery, dump truck bodies, hoppers, silos, crushers, and conveyor systems. In the construction and industrial sectors, you’ll see them in wear liners, buckets, and components for agricultural machinery. Their impressive strength and hardness help extend the lifespan of equipment, reduce downtime, and cut down on repair costs. Plus, the excellent workability and toughness of ARCELOR 450 Plates make them a reliable choice for demanding environments.
Samuel Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Abuja, Nigeria.
