In Abuja, United Arab Emirates, Samuel Steel is a top producer and supplier of DILLIDUR 450V Sheets and Plates, offering excellent wear-resistant steel solutions for demanding applications. Our DILLIDUR 450V plates, which are renowned for their exceptional hardness and high impact strength, are made to function in the most demanding conditions. Our carefully designed steel products are reliable and long-lasting because they meet international standards. Samuel Steel is dedicated to quality, on-time delivery, and client satisfaction while serving a range of industries throughout the United Arab Emirates and the Middle East, including mining, construction, and material handling.
The alloyed, heat-treated, wear-resistant steel DILLIDUR 450V has a hardness of about 450 HBW. Carbon, manganese, chromium, molybdenum, nickel, and boron are among its constituents, which improve toughness and abrasion resistance. This grade offers a yield strength of roughly 1000 MPa and a tensile strength of roughly 1350 MPa. With the right techniques, it also provides good weldability and outstanding impact resistance. DILLIDUR 450V’s mechanical characteristics make it appropriate for uses where increased structural performance, lower maintenance costs, and longer wear life are crucial.
Item: Dillidur 450V
Thickness : 5mm to 150mm
Length : 6,000mm to 12,000mm
Width : 1,500mm to 2,500mm
Heat Treatment: N, Q+T
Surface Point : EP, PE, HDP, SMP, PVDF
| C | Si | Mn | P | S | Mo | Ni | Cu | Cr | V | Nb | B |
| ≤ 0.25 | ≤ 0.70 | ≤ 1.60 | ≤ 0.025 | ≤ 0.010 | ≤ 0.50 | ≤ 0.80 | ≤ 0.30 | ≤ 1.50 | ≤ 0.08 | ≤ 0.05 | ≤ 0.005 |
| Grade | Mechanical Property | Charpy V Impact Test | |||
| DILIDUR 450V | Yield | Tensile | Elongation | Degree | longitudinal |
| Min Mpa | Mpa | Min % | -20 | J | |
| 950 | 1400 | 11 | 35 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1/8″ | 3/8″ | 3/4″ | 1-1/2″ | 3″ |
| 3/16″ | 1/2″ | 1″ | 2″ | 4″ |
| 1/4″ | 5/8″ | 1-1/4″ | 2-1/2″ | Â |
| *1/8″ thick plate is available in one size only 60″x 120″. The 3/6″ thick plate is available only as 48″ x 144″ and 96″ x 144″. | ||||
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
Samuel Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Abuja, Nigeria.
